Specializing in the Production of ACP901 LED Vision Chart

description1

Zipper closure 1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout

Description

Features:

1. Chinese and English languages could be selected.

2. The testing distance could be changed flexibly to meet with different user’s demands.

3. Several visual units are available.

4. The red & green value can be referred to the clinical situation.

5. Reversible optotypes and charts are suitable for the mirrored room.

6. The sizes of all charts depend on the working distance.

7. The LED screen is power-saving.

8. The professional contrast sensitivity measure can be made with the Gamma Calibration feature.

9. The software of ACP901 will be updated every two months. Software upgrade is provided for free during the lifetime of ACP901

10. New CNT test is more scientific, effective and directive. CNT curve will be formed and displayed on the screen when the test is finished.

11. Better user experience – all test icons are listed on home interface

12. Quick test list – pick ten (or less) frequently used tests to establish your own quick test list

13. V style optotypes arrangement – avoid optotypes congested on the screen

14. Excellent programming gives full play to the features of CPU

ACP901 advanced parameter setting experience

The built-in software of ACP901 is developed on Linux platform. All the optotypes and charts are vector graph. In order to be adaptable to various clinical conditions and offer a better operating experience to customers. We design a user-friendly parameter setting interface of ACP901

Change the parameter

What you do: press a button on remote controller

What ACP901 does: redraw the optotypes and charts on based of defined parameters.

Parameters:

Screen	Type	17-inch XGA panel with long-lasting backlight
	Resolution	1280*1024 pixels
	Brightness	160cd/m²(min)
Charts	Optotypes	Tumbling E, Landolt C, Alphabet, Numbers, Children
	Mask type	Single Mask, Horizontal Mask, Vertical Mask, White/Black Mask, Red/Green Mask
	Special chart	ETDRS, Contrast Sensitity Test, Contrast Test, Ishihara, Cross Cylinder, Astigmatic Fan Dial, Cross Grid, Fixation Spot Test, Stereo Test, Red/Green Panel, Worth Four-Dot Test, Red/Green Balance, Street Lamp, Horizontal Coincidences, Vertical Coincidences, Schober
Other functions	Video playing, Audio playing, Randomization Optptypes playing, Mirror function, Screen Saver function, Standby function
Visual Unit	Decimal	0.04~2.0
	Snellen (ft)	20/500~20/10
	Snellen (m)	6/150~6/3
	LogMAR	-0.3~1.4
	5-Grade	3.6~5.3
Working Distance	2m ~ 7m (in steps of 0.1m) 6ft ~ 24ft (in steps of 0.5ft)
Working Distance	Low vision chart: 0.6~1.5m, 0.1m/step
Power Supply	Input	AC220V ~ 230V ±10%, 50/60HZ
Power Supply	Consumption	20w
Remote Controller	IR Remote, 2*AAA Batteries
Standard accessories	Remote Controller, Wall Bracket, Desk Bracket, Red/Green Glasses, Opyotypes Card, Power Cable, AC-DC Adapter
Optional accessories	Desk support, Ground Support

Packing:
One carton
Gross weight: 10kgs
Dimension: 55*46*25cm
