APS-AER Fundus Camera
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Description
Parameters:
General:
1. Working mode: Non-mydriatic
2. Eye position aid: Alignment dots
3. Observing: Monitor + Anterior LCD
4. Resolution: 12M Max.
5. Field of view: 45 degree
6. Patient dioptor range: -10D to +10D
7. Working distance: F-B 40mm, L-R 120mm, U-D 80mm
8. Horizontal tilting: ±30º
9. Chin rest distance: 70mm
10. Electric-table distance: 200mm
11. Fixation: External LED + Internal target
12. Light source: IR + LED +FLASH
Electrical:
1. Power supply: AC220V/50HZ, 110V/60HZ
2. Working temperature: -5º ~ 40º
3. Working humidity: 0% ~ 85%
Physical:
1. Dimension: 35*55*60cm
2. Weight: 50kgs
Software:
1. Image post processing: brightness, contrast, gamma, color, smooth, sharp etc.
2. Focus processing: measuring, marking, patching up etc.
3. Documents management: record, search, sort, report etc.
Packing:
Four cartons
Computer part: 35kgs 600*500*785mm
Optics part: 15kgs 530*530*345mm
Tabletop part: 27kgs 480*420*570mm
Motorized Table: 25kgs 710*520*570mm
Logistics Information
- 1. Seafreight or Airfreight Service: AIR SEA TRANSPORT INC. (http://www.airseagroup.com.cn)
- 2. Express: DHL, FEDEX, UPS, TNT, EMS With special discount, our company always selects DHL as our main express service.
- 3. Other: The customer can nominate your usual forwarder.
