S260 LED Slit Lamp Microscope
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Description
Parameters:
1. Slit lamp microscope type: Galilean system
2. Magnification: 5 steps
3. Total magnifications: 6X, 10X, 16X, 25X,40X
4. Ocular magnification: 12.5X
5. Inter pupil distance: 52mm～78mm
6. Ranger of adjusting eyepieces: +6D to -6D
7. Object image field (Ø in mm): 34.7(6X), 22(10X), 13.5(16X), 8.5(25X), 5.5(40X)
8. Slit image width: 0～14mm continuous (slit becomes a circle at 14mm)
Slit image length: 1～14mm continuous
9. Light source: 3V/3W LED lamp
10. Slit image radial range: 0～180°
11. Filters: Heat aborption, grey, redfree(green), cobalt blue
12. Illumination fields Ø in mm: 0.2/3.5/8/14/1~14 continuous
13. Illumination intensity: ≥50KLX
14. Operation: Single handed 3-dimensional operation of the joystick
15. Range of adjustment: 110mm (longitudinal)
110mm (lateral)
30mm (vertical)
15mm(fine)
16. Chin-rest: Fixation: Red led, Vertical adjustment: 80mm
17. Input power: 220V/50HZ, 110V/60HZ
18. Output power: 30VA (max)
19. Output voltage : Light source 6V continuous, fixation 3V
20. Gross weight: 22Kg
Packing:
One carton
Gross weight: 22kgs
Dimension: 75*50*60cm
Logistics Information
- 1. Seafreight or Airfreight Service: AIR SEA TRANSPORT INC. (http://www.airseagroup.com.cn)
- 2. Express: DHL, FEDEX, UPS, TNT, EMS With special discount, our company always selects DHL as our main express service.
- 3. Other: The customer can nominate your usual forwarder.
